Front Return Air Handler Unit Features:
- Multi-Speed ECM motor for energy savings
- Insulated Cabinet – Galvanized steel with paint on all panels. Thermal insulator cover all inside panels to reduce heat and cooling losses and prevent condensed water accumulation
- Compact wall-mount design enables installation in tight spaces
- Front or bottom return
- All copper tube with aluminum fin coil
- Heat-pump with optional field installed electrical heat kit
- Thermoplastic drain pan
- Expansion Devise – Use TXV as expansion device
- Built in filter rack – Detachable air filter for cleaning or renewal
- Primary and secondary drain connections to meet FHA requirement
Top-Discharge Condensing Unit Features:
- Pre Charged with R410a environmentally friendly refrigerant
- 2.75 ton capacity
- Scroll compressor with quick reactivity, stronger and stable operation
- All Copper Coil with Gold Fin: this convenient technology will allow your equipment to have a longer functional life where traditional coil coatings fail; especially in high humidity and salinity environments that promote corrosion
- Painted galvanized steel cabinet and base pan
- Ultra-quiet operation. Max. 65 decibels
For better performance, we recommend installing this air handler with its matching top-discharge condensing unit:
| CAC – FAHC Series | |
| Condensing Unit | Air Handler |
| CAC3613HA15 | FAHC36HA15 |
| TECHNICAL SPECIFICATIONS | |||
| Condensing Unit | Air Handler | ||
| SKU | CAC3613HA15 | FAHC36HA15 | |
| BTU | 33,000 | 33,000 | |
| Ton | 2.75 | 2.75 | |
| Power Supply |
208~230V/1Ph/60Hz
|
208~230V/1Ph/60Hz
|
|
| SEER2 | 14.3 | 14.3 | |
| Heat Pump | Yes | Yes | |
| Refrigerant Gas | R410A | R410A | |
| Compressor Brand | LG | – | |
| Compressor Type | Scroll | – | |
| Installation Kit | No | No | |
| DIMENSIONS | CAC3613HA15 | FAHC36HA15 | |
| Net Dimension (W*H*D) | 29-1/7 × 25 × 29-1/7 in
740 × 633 × 740 mm |
20-3/5 x 36 x 15 in
524 x 915 381 mm |
|
| Packing Dimension (W*H*D) | 30-3/10 x 26-1/5 x 30-3/10 in
770 x 665 x 770 mm |
23-1/5 x 39-2/5 x 17-7/10 in
590 x 1000 x 450 mm |
|
| WEIGHT | |||
| Net | 166 lb
75.5 kg |
112 lb
51 kg |
|
| Packing | 173 lb
78.5 kg |
123 lb
56 kg |
|
WARRANTY
Ten (10) years on parts and compressor if valid warranty registration
- Register the unit for Limited Warranty within 60 days of installation at everwell-ac.com/warranty
- If the unit is covered under the Limited Warranty and requires replacement parts, the parts will be provided at no cost, although shipping will need to be covered by the client.
