Air Handler Unit Features:
- Multi-Speed ECM motor for energy savings
- Insulated Cabinet – Galvanized steel with paint on all panels. Thermal insulator cover all inside panels to reduce heat and cooling losses and prevent condensed water accumulation
- Compact wall-mount design enables installation in tight spaces
- Front or bottom return
- All copper tube with aluminum fin coil
- Heat-pump with optional field installed electrical heat kit
- Thermoplastic drain pan
- Expansion Devise – Use TXV as expansion device
- Built in filter rack – Detachable air filter for cleaning or renewal
- Primary and secondary drain connections to meet FHA requirement
Top-Discharge Condensing Unit Features:
- Pre Charged with R410a environmentally friendly refrigerant
- 2.33 ton capacity
- Scroll compressor with quick reactivity, stronger and stable operation
- All Copper Coil with Gold Fin: this convenient technology will allow your equipment to have a longer functional life where traditional coil coatings fail; especially in high humidity and salinity environments that promote corrosion
- Painted galvanized steel cabinet and base pan
- Ultra-quiet operation. Max. 65 decibels
For better performance, we recommend installing this air handler with its matching top-discharge condensing unit:
| CAC – AHC Series | |
| Condensing Unit | Air Handler |
| CAC3013HA15 | AHC30HA15 |
